Timber Frame Treatment Pump

How to launch the 8L ECO HP frame treatment pump?

The red oil tank cap is only used for transport purposes, before using it for the first time, it is necessary to replace it with the yellow cap. 1. Check the oil level. 2. Check the condition of the strainer. 3. Connect the return hose and the high pressure hose. 4. Unscrew the pressure control knob completely and keep it pressed. 5. Wait for the product to flow out of the return hose. 6. To obtain the desired pressure, screw in the pressure control knob. It is not necessary to pierce the decompression cap on the pressure gauge, just make sure you build up the pump pressure very gradually.

How to check the oil level of the 8L ECO HP frame treatment pump?

To maintain the pump in good working condition, it is essential to check and refill the oil level of your 8L ECO pump.

How to purge the pressure gauge of the 8L ECO HP frame treatment pump?

In this video, we explain how to purge the pressure gauge when using the pump for the first time.

How to install a quick coupling on the 8L ECO HP frame treatment pump?

The following video shows you how to install a quick coupling on the 8L ECO pump. This system saves you time when setting up the pump.

How to change the valves of the 8L ECO HP treatment pump?

Performing regular maintenance of your pump will keep it reliable and efficient. This video explains how to perform a quick and east maintenance, changing the valves of the high pressure MABI pump.

How to change the sealing kit of the 8L ECO HP treatment pump?

After each use, clean the filter of the suction pipe and the gun. Rinse the pump from time to time with diesel fuel (cleaning and maintenance). Check the oil level regularly. The first oil change should be made after a maximum of 50 hours, then change the oil every 500 hours (BP VANELLUS C4 type). Storage: store in a frost-free place and run a greasy petroleum product or oil mixed with water through the pump.

How to change the regulator kit of the 8L ECO HP treatment pump?

The video shows you how to change the pump's regulator kit (pressure ring, seals, packing,...) in a few steps.
